SCARA ROBOTIC ARMS – Z-Arm-4160B Collaborative Robotic Arm

Short Description:

The SCIC Z-Arm 4160B is designed by SCIC Tech, it is lightweight collaborative robot, easy to program and use, support SDK. In addition, it is collision detection supported, namely, it would be automatic to stop when touching human, which is smart human-machine collaboration, the security is high.

Z axis stroke: 410mm (Height can be customized)

Linear speed: 2000mm/s (payload 4kg)

Repeatability: ±0.02mm

Standard payload: 4kg

Maximum payload: 5kg

Send email to us

Product Detail

Product Tags

Main Category

Industrial robot arm /Collaborative robot arm / Electric gripper/Intelligent actuator/Automation solutions

Application

SCIC Z-Arm cobots are lightweight 4-axis collaborative robots with drive motor built inside, and no longer require reducers like other traditional scara, reducing the cost by 40%. SCIC Z-Arm cobots can realize functions including but no limited to 3D printing, material handling, welding, and laser engraving. It is capable of greatly improving the efficiency and flexibility of your work and production.

Features

High Precision
Repeatability
±0.02mm

Customized Z-axis
0.1-0.8m

Large Payload
Stand 4kg
Max 5kg

Higher Speed
Max linear speed 2m/s
(Stand load 5kg)

Big Arm Span, High Accuracy 4-Axis Robot Arm with Easy to Use

High Precision

Repeatability: ±0.02mm

Big Arm Span

J1-Axis: 325mm, J2-Axis: 275mm

Customized Z-Axis

The up-down stroke can be customized between 0.1m-0.8m

Space-Saving

Drive/Controller is Built-in

Simple and Easy to use

The newcomer who didn't know robot arm also can be easy to use, the interface is opening.

High Speed

Its speed is 2000mm/s under the load of 4kg

Specification Parameter

The SCIC Hitbot Z-Arm 4160B is designed by SCIC Tech, it is lightweight collaborative robot, easy to program and use, support SDK. In addition, it is collision detection supported, namely, it would be automatic to stop when touching human, which is smart human-machine collaboration, the security is high.

Z-Arm 4160B Collaborative Robot arm	Parameters
1 axis arm length	325mm
1 axis rotation angle	±90°
2 axis arm length	275mm
2 axis rotation angle	±164° Optional: 15-345deg
Z axis stroke	410 Height can be customized
R axis rotation range	±1080°
Linear speed	2000mm/s (payload 4kg)
Repeatability	±0.02mm
Standard payload	4kg
Maximum payload	5kg
Degree of freedom	4
Power supply	220V/110V50-60HZ adapt to 48VDC peak power 960W
Communication	Ethernet
Expandability	Built-in integrated motion controller provides 24 I/O + under-arm expansion
Z-axis can be customized in height	0.1m~0.8m
Z-axis dragging teaching	/
Electrical interface reserved	Standard configuration: 24*23awg (unshielded) wires from the socket panel through the lower arm cover Optional: 2 φ4 vacuum tubes through the socket panel and flange
Compatible HITBOT electric grippers	Z-EFG-8S/Z-EFG-12/Z-EFG-20/Z-EFG-20S/Z-EFG-20F/Z-ERG-20C/Z-EFG-30/Z-EFG-50/Z-EFG-100
Breathing light	/
Second arm range of motion	Standard: ±164° Optional: 15-345deg
Optional accessories	/
Use environment	Ambient temperature: 0-45°C Humidity: 20-80%RH (no frost)
I/O port digital input (isolated)	9+3+forearm extension (optional)
I/O port digital output (isolated)	9+3+forearm extension (optional)
I/O port analog input (4-20mA)	/
I/O port analog output (4-20mA)	/
Robot arm height	860mm
Robot arm weight	410mm stroke net weight 36.5kg
Base size	250mm250mm15mm
Distance between base fixing holes	200mm200mm with four M820 screws
Collision detection	√
Drag teaching	√

Ideal Selection for Lightweight Assembly Tasks

Z-Arm XX60B is a 4-axis robot arm with big arm span, occupying small area, very suitable to put on work station or inside machine, it is an ideal selection for lightweight assembly task.

Lightweight with Big Rotation Angle

The product weight is about 36.5kg, its max load can be up to 5kg, the rotation angel of 1-axis is ±90°, the rotation angle of 2-axis is ±164°, the rotation range of R-axis can be up to ±1080°.

Big Arm Span, Wide Application

Z-Arm XX60B has a long arm span, the length of 1-axis is 325mm, the length of 2-axis is 275mm, its linear speed can be up to 2000mm/s under the load of 4kg.

Flexible to Deploy, Fast to Switch

The Z-Arm XX60B has the characteristics of lightweight, space-saaving and flexible to deploy, it is suitable to deploy in many applications, and it would not change the former production layout, including fast to switch process sequence and complete small batch of production, etc.

DragTeaching to Complete Program

The software is base on graphic design, it has provided point, output signal, electric gripper, tray, delayed, sub-process, reset and other basic functional module, users can drag module to control robot arm in programming area, the interface is simple, but function is powerful.
