SMART FORKLIFT – SFL-CDD16 Laser SLAM Stacker Smart Forklift

Short Description:

The SRC-owned laser SLAM Smart Forklifts come equipped with an internal SRC core controller along with 360° safety to meet the requirements of loading and unloading, sorting, moving, high-elevation shelf stacking, material cage stacking, and pallet stacking application scenarios. This series of robots features a wide range of models, a large variety of loads, and supports customization to provide powerful solutions for the moving of pallets, material cages, and racks.

Rated Load Capacity: 1600kg

Run Time: 8~10h

Lifting Height: 3000mm

Minimum Turning Radius: 1340+200mm

Positioning Accuracy: ±10mm, ±0.5°

Driving Speed (Full load / No load): 2/2 m/s

Send email to us

Product Detail

Product Tags

Main Category

AGV AMR / AGV automatic guided vehicle / AMR autonomous mobile robot / AMR robot stacker / AMR car for industrial material handling / laser SLAM small stacker automatic forklift / warehouse AMR / AMR laser SLAM navigation / AGV AMR mobile robot / AGV AMR chassis laser SLAM navigation / unmanned autonomous forklift / warehouse AMR pallet fork stacker

Application

Feature

·Rated Load Capacity: 1600kg

·Run Time: 8~10h

·Lifting Height: 3000mm

·Minimum Turning Radius: 1340+200mm

·Positioning Accuracy: ±10mm, ±0.5°

·Driving Speed (Full load / No load) : 2/2 m/s

● SLAM Navigation, Precise and Convenient

SLAM navigation with an accuracy of ±10 mm, without reflectors and easily deployed.

● 2 m/s Running Speed, Faster and More Efficient

The maximum running speed is 2 m/s in both no-load and full-load cases.

● 3 m Lifting with Stable Load Capacity (1.6 T)

The load capacity will not decrease and remains at 1.6 T when lifting to 3 m.

● New Industrial Design

Family-based industrial design and multi-module quality assurance (operation panel, sensor bracket, wiring harness, etc.) for easier disassembly, assembly, and maintenance.

● Pallet Recognition, Precise and Efficient

High-precision identification and precise pallets forking to guaranteed handling speed.Identification of international standard pallets, European standard pallets, and non-standard pallets.

● Diversified Choices and Safe Navigation

360° obstacle detection laser scanning, with 3D cameras, bumper strip, distance sensor, and other sensors.

Specification Parameter

Technical Parameters	Product name	Laser SLAM small ground smart forklift
	Driving mode	Automatic navigation, handheld driving
	Navigation type	Laser SLAM
	Tray type	3-stringer pallet
	Rated load capacity (kg)	1600
	Dear weight (with battery) (kg)	1090
	*Navigation position accuracy^ (mm)**	±10
	*Navigation angle accuracy^ (°)**	±0.5
	Fork in-position accuracy (mm)	±10
	Standard lifting height (mm)	3000
	*Vehicle size: length width * height (mm)**	183210502040
	*Fork size: length width * height (mm)**	122018555
	Fork outer width (mm)	600
	Right-angle stacking channel width, pallet 1000×1200 (1200 placed across forks) (mm)	-
	Right-angle stacking channel width, pallet 800×1200 (1200 placed along the fork) (mm)	2230+200
	Minimum turning radius (mm)	1340+200
Perfermance parameters	Driving speed: full load / no load (m/s)	2 / 2
	Lifting speed: full load / no load (mm/s)	100 / 180
	Lowering speed: full load / no load (mm/s)	245 / 230
Wheel parameters	Wheel number: driving wheel / balance wheel / bearing wheel	1 / 2 / 4
Battery parameters	Battery specifications (V/Ah)	24 / 173 (lithium iron phosphate)
	Battery weight (kg)	60
	Comprehensive battery life (h)	8-10
	Charging time (10% to 80%) (h)	2
	Charging method	Manual / Automatic
Certifications	ISO 3691-4	-
	EMC/ESD	●
	UN38.3	●
Function configurations	Wi-Fi roaming function	●
	3D obstacle avoidance	○
	Pallet recognition	○
	Cage stack	○
	High shelf pallet recognition	○
	Pallet damage detection	○
	Pallet stacking and unstacking	○
Safety configurations	E-stop button	●
	Sound and light indicator	●
	360° laser protection	●
	Bumper strip	●
	Fork height protection	●
